Peb -Dimensional Tov Khoom rau Kev Siv Tshuaj, Tshuaj & Khoom Noj Hmoov
JB series peb- qhov sib tov sib xyaw yog dav siv rau kev sib xyaw ntawm cov khoom siv hmoov los ntawm lub khw muag tshuaj, tshuaj, thiab khoom noj khoom haus, nrog rau kev sib xyaw ceev thiab txawm tias sib xyaw ntawm ntau yam khoom sib txawv ntawm qhov sib txawv thiab qhov sib txawv. Qhov no 3d tov khoom muaj qhov zoo ntawm kev ua haujlwm ruaj khov, tsis tshua muaj suab nrov, siab loading coefficient, thiab lub sijhawm sib tov luv.
Baoli Machinery yog ib qhov zoo tshaj plaws 3D hmoov tov khoom manufacturers & lwm tus neeg nyob hauv Suav teb. Yog tias koj tab tom nrhiav 3D sib xyaw tshuab, txais tos hu rau peb!
-
![3D hmoov tov khoom]()
Ntxiv rau Kev Nug -
![Pharmaceutical Turbula 3D Powder Tov Khoom Tshuab]()
Pharmaceutical Turbula 3D Powder Tov Khoom Tshuab
Ntxiv rau Kev Nug -
![Tshuaj hmoov sib tov tshuab]()
Ntxiv rau Kev Nug -
![Me Hmoov Tov Khoom Tshuab]()
Ntxiv rau Kev Nug -
![Hmoov Blender Tshuab]()
Ntxiv rau Kev Nug -
![Tshuaj hmoov tov tshuab]()
Ntxiv rau Kev Nug -
![Cov khoom siv hmoov Blender]()
Ntxiv rau Kev Nug -
![Hmoov Tshuab Tov Khoom]()
Ntxiv rau Kev Nug -
![Pharmaceutical Mixing Tshuab]()
Ntxiv rau Kev Nug
Video ntawm peb -sib cav sib tov
Txoj Cai Ua Haujlwm ntawm JB Series peb -Swing sib xyaw tshuab
Peb -Dimensional Motion:Lub tog raj kheej sib xyaw, uas tau tsav los ntawm lub ntsiab ncej, ib txhij ua axial, radial, thiab circumferential txav.
Cov txheej txheem sib xyaw ua ke:Convection, diffusion, thiab shear rog tshwm sim concurrently. Cov ntaub ntawv hauv lub thawv tsis tsuas yog txav mus los ntawm txhais tes xwb tab sis kuj tau nqa, tawg, thiab swb rau ib leeg.
Tsis Muaj Tuag Zones:Qhov kev ua haujlwm nyuaj no ua kom tag nrho qhov chaw ntim khoom ua qhov sib xyaw ua haujlwm zoo, tiv thaiv kev sib xyaw hauv zos tsis sib xws.
Mix Hindiaz :Rau cov khoom tawg yooj yim, siv lead ua-sensitive, lossis tshav kub- cov ntaub ntawv rhiab heev, 3D tov khoom muab ib qho chaw sib xyaw ua ke uas khaws cov yam ntxwv qub ntawm cov ntaub ntawv.
Tshwj xeeb:Nrog nws qhov tshwj xeeb peb -vav viav vias, txav mus rau qhov sib npaug, thiab dov txoj kev, lub tshuab 3D no tuaj yeem tsim kom muaj zog mem tes txav mus rau pem hauv ntej thiab sib tov cov ntaub ntawv tsis tu ncua. Qhov sib xyaw ua ke zoo heev yog qhov tshwm sim ntawm nws qhov hloov pauv vortex txav uas muaj lub zog gradients sab hauv. Nws kuj muaj qhov zoo ntawm kev khiav haujlwm du, tsis tshua muaj suab nrov, siab loading kom muaj nuj nqis, thiab lub sijhawm sib xyaw luv luv thiab.
Daim ntawv thov ntawm 3D tov khoom tshuab
1. Kev lag luam kws tshuaj
Qhov no yog qhov tseem ceeb tshaj plaws thiab dav siv teb rau 3D mixers. Vim lawv tsis yog- sib xyaw ua kom puas tsuaj, tsis muaj qhov chaw tuag, thiab kev yooj yim ntawm kev ntxuav (raws li GMP cov qauv), lawv tau siv hauv:
* Sib xyaw APIs thiab Excipients:Ua kom tiav cov khoom xyaw tshuaj nquag nrog ntau yam khoom ntxiv (xws li, cov khoom ntim, cov tshuaj tsis sib haum, cov roj nplua nyeem) ua ntej cov ntsiav tshuaj lossis tshuaj ntsiav tshuaj.
* Kev sib xyaw tshuaj suav tshuaj suav tshuaj:Sib tov hmoov los ntawm ntau yam tshuaj ntsuab hauv av.
* Ua kom cov ntsiab lus tshuaj tsis sib xws:Qhov tseem ceeb rau kev nyab xeeb thiab kev ua tau zoo ntawm cov tshuaj, qhov kev sib tw siab ntawm 3D mixers yog qhov tseem ceeb.
2. Kev lag luam zaub mov
* Seasoning thiab Spice Blending:Kev sib xyaw cov hmoov nplej, monosodium glutamate, ntsev, thiab lwm yam, los tsim cov seasonings sib xyaw.
* Khoom noj khoom haus ntxiv Mixing:Kev sib xyaw ua ke zoo ib yam li cov vitamins, minerals, thiab protein hmoov nrog cov ntaub ntawv hauv paus (xws li mis hmoov, nplej hmoov).
* Ntxiv Premixes:Ua ntej- sib xyaw cov khoom noj khoom haus ntxiv (piv txwv li, pigments, preservatives) nrog cov neeg nqa khoom kom ntseeg tau tias kev faib tawm hauv cov khoom kawg.
3. Kev lag luam tshuaj
* Dye thiab Pigment Mixing:Ua kom cov xim tsis sib xws ntawm cov xim xim rau cov khoom sib xws.
* Yas Masterbatch Mixing:Blending colorants, additives, thiab puag yas hais.
* Cov tshuaj zoo:Sib tov catalysts, ceramic hmoov, hlau hmoov, thiab lwm yam.
4. Veterinary Drug thiab Pub Kev Lag Luam
* Veterinary Drug Premixes:Diluting kab noj tshuaj nrog bulk carriers kom paub tseeb tias tsiaj noj.
* Pub Additives:Kev sib xyaw ua ke ntawm cov vitamins, amino acids, kab kawm, thiab lwm yam, nrog cov neeg nqa khoom noj.
Technical Specifications
| Qauv | Main Structural Dimensions (hli) | Ntim |
Max Chaw thau khoom |
Ceev |
Tshuab Qhov hnyav |
Tag nrho Hwj chim |
|||
| L | W1 | W2 | H | L | KG | Rpm/min | Kg | KW | |
| JB-50 | 1000 | 850 | 1400 | 1200 | 50 | 25 | 3-15 | 250 | 1.1 |
| JB-100 | 1250 | 1250 | 1775 | 1600 | 100 | 50 | 3-12 | 600 | 2.2 |
| JB-200 | 1400 | 1450 | 1800 | 1750 | 200 | 100 | 3-12 | 900 | 2.2 |
| JB-400 Nws | 1650 | 1600 | 2235 | 1950 | 400 | 200 | 3-12 | 1200 | 4 |
| JB-600 Nws | 1750 | 1600 | 2435 | 2160 | 600 | 300 | 3-12 | 1600 | 5.5 |
| JB-800 Nws | 2000 | 1900 | 2690 | 2550 | 800 | 400 | 3-12 | 2000 | 7.5 |
| JB-1000 Nws | 2100 | 1950 | 2805 | 2640 | 1000 | 500 | 3-10 | 2200 | 11 |
| JB-1200 Nws | 2200 | 2200 | 2950 | 2750 | 1200 | 600 | 3-8 | 2500 | 11 |
| JB-1500 Nws | 2250 | 2500 | 3225 | 2930 | 1500 | 750 | 3-8 | 2900 | 15 |
Ntau cov duab
FAQ
Q1: Nws puas yooj yim los ntxuav peb - qhov sib tov sib xyaw?
1) Cov qauv qhib ceev: siv ceev- qhib clamps, thiab lwm yam, nws tuaj yeem qhib tau sai yam tsis muaj cuab yeej.
2) Tsis muaj cov kab tuag tsim: Sab hauv phab ntsa ntawm lub thawv yog du thiab ua kua, tsis txhob muaj cov khoom seem.
3) Txoj kev ntxuav: Txhawb ntau txoj hauv kev xws li ntxuav kom qhuav thiab ntxuav ntub.
Q2: Yuav ua li cas tswj cov plua plav overflow thiab tiv thaiv qhov chaw tsim khoom?
A: Peb muaj ntau txoj kev xaiv: lub cuab yeej tuaj yeem tsim los ua cov qauv ntim tag nrho, nruab nrog lub hnab ntim khoom sib xyaw lossis lim plua plav collector raws li kev xaiv khoom siv.
Q3: Puas yuav muaj cua sov thaum lub sijhawm crushing? Yuav tswj qhov kub li cas?
A: Mechanical crushing yeej ua kom sov. Rau cua sov- cov ntaub ntawv rhiab heev, peb muab ntau yam kev ua kom txias:
1) Ua - hauv lub tsho txias: ua kom lub tshuab sib tsoo los ntawm cov dej txias.
2) Airflow cua txias: Siv lub tshuab cua txias kom txias cov kab noj hniav.
Q4: Lub neej ntev ntawm cov khoom hnav yooj yim xws li cov hniav, cov ntxaij vab tshaus, thiab cov nplhaib iav yog dab tsi?
A: Lub neej ntev nyob ntawm qhov hardness thiab abrasion tsis kam ntawm cov khoom. Rau siab - cov ntaub ntawv hardness, peb muab cov khoom tsis zoo ua los ntawm cov khoom siv siab heev xws li hnav- cov alloys resistant thiab tungsten carbide kom ntev lawv lub neej kev pab thiab txo cov nqi tu.
Q5: Koj puas muab kev pabcuam tomqab- muag thiab kev pabcuam?
A: Yog lawm, peb muab kev txhawb nqa tom qab- muag khoom, suav nrog kev taw qhia chaw taws teeb, thiab tuaj yeem npaj rau cov kws ua haujlwm los pab rau ntawm -qhov chaw teeb tsa, commissioning, thiab kev cob qhia cov neeg ua haujlwm rau cov haujlwm loj.
Q6: Koj tuaj yeem teb sai npaum li cas thaum muaj teeb meem tshwm sim?
A: Peb muab 7x24-teev kev pabcuam xovtooj kub. Rau cov teeb meem ceev, peb cov engineers yuav xub muab cov kev taw qhia chaw taws teeb los ntawm kev hu xov tooj / video los daws lawv. Yog tias tsis tuaj yeem daws tau, peb yuav npaj cov engineers mus rau qhov chaw sai li sai tau raws li qhov xwm txheej.
Q7: Yuav ua li cas kom tau txais cov khoom seem?
A: Peb khaws cov khoom muag ntawm cov khoom siv feem ntau siv thiab tuaj yeem xa lawv sai. Koj tuaj yeem tso qhov kev txiav txim ncaj qha los ntawm koj tus neeg muag khoom. Peb muab thawj cov khoom seem kos duab thiab cov npe rau koj yooj yim hauv kev tswj hwm.
Ib - nres Peb -Dimensional Mixer Manufacturers & Cov neeg muag khoom nyob rau hauv Suav teb
Baoli Machinery tau lees paub tias yog lub ntiaj teb cov khoom lag luam ntawm cov hmoov thev naus laus zis kev daws teeb meem thiab muaj 3d hmoov tov khoom thiab cov kev pabcuam tshwj xeeb. Peb muaj cov kws tshaj lij R & D thiab pab pawg tsim khoom uas txhawb nqa cov kev pabcuam customized rau cov khoom ntim, cov ntaub ntawv, thiab cov txheej txheem tswj, ua kom haum raws li cov neeg siv khoom xav tau thiab chaw ua haujlwm. Txawm hais tias nws yog kev yuav khoom ntau, kev sib koom ua ke ntawm cov kab ntau lawm, lossis cov khoom siv kho kom haum rau kev kuaj sim, peb tuaj yeem muab tus nqi - cov kev daws teeb meem zoo. Yog xav paub ntxiv (xws li cov kev daws teeb meem, cov khoom siv hais lus, thiab ntawm - qhov chaw ua haujlwm), thov koj xav tiv tauj peb!
